Results:

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	TransformerType	Inductance	ET(Volt-Time)	TurnsRatio-Primary:Secondary	MountingType	Size/Dimension	Height-Seated(Max)
POE012-PD13050S POE TRANSFORMER, 12W, EPD13,150U Bourns Inc.	2,477	1.58	RFQ		Tape & Reel (TR)	-	Active	-	-	-	-	-	-	-
POE025-EP13050S POE TRANSFORMER, 25W, EP13, 100U Bourns Inc.	3,115	1.58	RFQ		Tape & Reel (TR)	-	Active	-	-	-	-	-	-	-
PA1323NLT PULSE XFMR 1:1 600UH Pulse Electronics Power	2,143	1.63	RFQ	Datasheet	Tape & Reel (TR)	-	Active	-	600µH	21.7VµS	1:1	Surface Mount	0.280 L x 0.375 W (7.11mm x 9.52mm)	0.210 (5.33mm)
PH9085.011NLT IND PWR 3.0X3.0X1.2 1.02MH SMT Pulse Electronics Power	1,245	2.97	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	-	-	-	-	Surface Mount	0.319 L x 0.280 W (8.10mm x 7.10mm)	0.200 (5.08mm)
ALANS100X1-1E82DT LAN SGL 100B XFMR&CMC&AUTO 12PIN Abracon LLC	3,372	1.72	RFQ	Datasheet	Tape & Reel (TR)	-	Active	-	350µH	-	1CT:1CT	Surface Mount	0.583 L x 0.460 W (14.81mm x 11.68mm)	0.197 (5.00mm)
POE072-PD13120S POE TRANSFORMER, 72W, EPD13,100U Bourns Inc.	2,430	1.64	RFQ		Tape & Reel (TR)	-	Active	-	-	-	-	-	-	-
PA2009NLT PULSE XFMR 2.5:1:1 1.49MH Pulse Electronics Power	2,033	1.64	RFQ	Datasheet	Tape & Reel (TR)	-	Active	-	1.49mH	47VµS	2.5:1:1	Surface Mount	0.355 L x 0.340 W (9.02mm x 8.64mm)	0.300 (7.62mm)
HCTSM80803AAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	2,874	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	250µH	11.0VµS	8:3	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM80304BAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	2,273	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	300µH	11.0VµS	3:4	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM80308BAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	2,743	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	300µH	11.0VµS	3:8	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM80809AAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	2,897	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	250µH	11.0VµS	8:9	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM80403AAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	2,255	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	250µH	11.0VµS	4:3	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM80102AAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	5,000	3.13	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	HCT	Active	Isolation and Data Interface (Encapsulated)	250µH	11.0VµS	1:2	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM80201AAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	2,583	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	250µH	11.0VµS	2:1	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM81017CAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	2,153	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	350µH	11.0VµS	10:17	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM80305BAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	3,014	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	300µH	11.0VµS	3:5	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
HCTSM80910BAL-E XFMR 3.3-5V/3.3-15V,350MA PK TR Bourns Inc.	2,610	1.67	RFQ	Datasheet	Tape & Reel (TR)	HCT	Active	Isolation and Data Interface (Encapsulated)	300µH	11.0VµS	9:10	Surface Mount	0.484 L x 0.425 W (12.30mm x 10.80mm)	0.256 (6.50mm)
SM75057PEL PULSE XFMR 1:2 TX 1:2 RX 1.2MH Bourns Inc.	2,007	1.68	RFQ	Datasheet	Tape & Reel (TR)	-	Active	-	1.2mH	-	1:2 Transmitter, 1:2 Receiver	Surface Mount	0.504 L x 0.272 W (12.80mm x 6.90mm)	0.222 (5.65mm)
76611/2C PULSE XFMR Murata Power Solutions Inc.	2,207	1.72	RFQ	Datasheet	Tube	766	Active	General Purpose	-	-	-	Through Hole	0.500 L x 0.350 W (12.70mm x 8.89mm)	0.250 (6.35mm)
HCTSM81017CAL-E1 XFRMR POWER 10:17 350UH SMD Bourns Inc.	3,014	1.73	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	HCT	Active	-	350µH	11.0VµS	10:17	Surface Mount	0.598 L x 0.425 W (15.20mm x 10.80mm)	0.256 (6.50mm)
