BC847BPN,115

Nexperia USA Inc. BC847BPN,115

Part No.:: BC847BPN,115

Manufacturer:: Nexperia USA Inc.

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: BC847BPN,115.pdf

Description:: TRANS NPN/PNP 45V 0.1A 6TSSOP

Quantity:: RFQ

Payment:

Shipping:

Product details

1. Overview of BC847BPN
The BC847BPN is a dual-channel NPN transistor from Nexperia in SOT363 (SC-88) surface-mount package. Each chip integrates two independent high-performance NPN transistors for low-power amplification, signal switching, and digital logic interface scenarios. Its compact package size (1.6 x 1.2mm) and high reliability make it ideal for space-constrained designs.

2. Key specifications
Polarity: Double NPN

Package: SOT363 (SC-88)

Maximum collector-emitter voltage (VCEO) : 45V

Maximum collector current (IC) : 100mA

Current gain (HFE) : 110~800 (distinguished by hierarchical suffixes, such as BC847BPN for general purpose)

Power consumption (Pd) : 250mW

Operating temperature range: -55°C to +150°C

Meet environmental standards: RoHS, halogen-free

3. Structure and performance advantages
Dual channel integration: Two independent transistors are integrated in a single package to reduce PCB space footprint.

High current gain: Wide HFE range for efficient signal amplification at low drive current.

Low saturation voltage drop: VCE(sat) typical value as low as 0.6V (IC=10mA), improve switching efficiency.

High frequency characteristics: cut-off frequency (fT) up to 100MHz, suitable for intermediate frequency signal processing.
4. Typical application scenarios
Signal amplification: audio pre-amplification, sensor signal conditioning.

Switch control: Drive relays, LED arrays, or low power loads.

Logic level conversion: Provides a voltage adaptation interface between the MCU and peripheral devices.

Digital circuit buffer: enhance signal driving ability, suppress noise interference.

5. Design suggestions
Layout optimization: SOT363 package pin spacing is small, it is recommended to use high-precision patch process to avoid welding short circuit.

Thermal management: Evaluate the heat dissipation conditions during continuous high current operation to ensure that the junction temperature does not exceed the rated value.

Paired use: The two-channel design supports symmetrical circuits (such as differential amplification) that need to match two transistor parameters.
6 Summary
The BC847BPN, with its dual-channel integration, high cost performance and wide compatibility, is a universal solution for low-power electronics design. Design engineers can flexibly apply to consumer electronics, industrial control and communication modules according to specific needs, significantly improving system integration and reliability.
BC847BPN

Packaging:
Tape & Reel (TR),Cut Tape (CT)
Series:
Automotive, AEC-Q101
ProductStatus:
Active
TransistorType:
NPN, PNP
Current-Collector(Ic)(Max):
100mA
Voltage-CollectorEmitterBreakdown(Max):
45V
VceSaturation(Max)@IbIc:
300mV @ 5mA, 100mA
Current-CollectorCutoff(Max):
15nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
200 @ 2mA, 5V
Power-Max:
300mW
Frequency-Transition:
100MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
