Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	LogicType	NumberofCircuits	NumberofInputs	Features	Voltage-Supply	Current-Quiescent(Max)	Current-OutputHighLow	LogicLevel-Low	LogicLevel-High	MaxPropagationDelay@VMaxCL	OperatingTemperature	MountingType
MC14011BDT NAND GATE onsemi	4,032	0.10	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
CD4030CSJX XOR GATE Fairchild Semiconductor	4,000	0.10	RFQ	Datasheet	Bulk	-	Active	XOR (Exclusive OR)	4	2	-	3V ~ 15V	1 µA	-	-	-	150ns @ 10V, 15pF	-55°C ~ 125°C	Through Hole
MC74ACT20ML1 NAND GATE, ACT SERIES, 4-INPUT onsemi	4,000	0.10	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
4012BDC NAND GATE, CMOS National Semiconductor	3,723	0.10	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
MC74AC86DT XOR GATE, AC SERIES onsemi	3,588	0.10	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
7450PC AND-OR-INVERT GATE National Semiconductor	3,209	0.10	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74AHC00D-Q100118 NAND GATE, AHC/VHC/H/U/V SERIES NXP USA Inc.	5,326	0.11	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
MC74HC00AFL1 IC GATE NAND 4CH 2-INP SOEIAJ-14 onsemi	10,000	0.12	RFQ		Bulk	74HC	Active	NAND Gate	4	2	-	2V ~ 6V	1 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	13ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
74VCX32MTCX IC GATE OR 4CH 2-INP 14TSSOP Fairchild Semiconductor	9,995	0.12	RFQ	Datasheet	Bulk	74VCX	Obsolete	OR Gate	4	2	-	1.2V ~ 3.6V	20 µA	24mA, 24mA	0.7V ~ 0.8V	1.6V ~ 2V	2.8ns @ 3.3V, 30pF	-40°C ~ 85°C	Surface Mount
MC74F10N NAND GATE, F/FAST SERIES, 3 FUNC onsemi	9,562	0.12	RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74AC32SJ IC GATE OR 4CH 2-INP 14SOP Fairchild Semiconductor	9,473	0.12	RFQ	Datasheet	Tube	74AC	Obsolete	OR Gate	4	2	-	2V ~ 6V	2 µA	24mA, 24mA	0.9V ~ 1.65V	2.1V ~ 3.85V	7.5ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
SC14S70FEL LOG CMOS XCLUSIVE OR GATE onsemi	9,000	0.12	RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74VCX38M IC GATE NAND OD 4CH 2-INP 14SOIC Fairchild Semiconductor	8,570	0.12	RFQ	Datasheet	Tube	74VCX	Obsolete	NAND Gate	4	2	Open Drain	1.2V ~ 3.6V	20 µA	-, 24mA	0.7V ~ 0.8V	1.6V ~ 2V	2.8ns @ 3.3V, 30pF	-40°C ~ 85°C	Surface Mount
MC74AC08DT AND GATE, AC SERIES onsemi	8,089	0.12	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
MC74HC02AFELG IC GATE NOR 4CH 2-INP SOEIAJ-14 onsemi	7,748	0.12	RFQ	Datasheet	Bulk	74HC	Active	NOR Gate	4	2	-	2V ~ 6V	1 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	13ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
MC74ACT00DT IC GATE NAND 4CH 2-INP 14-TSSOP onsemi	7,258	0.12	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
MC74AC32DT IC GATE OR 4CH 2-INP 14-TSSOP onsemi	7,120	0.12	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
MC74F10M TRIPLE 3-INPUT NAND GATE onsemi	6,920	0.12	RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
SN74HC11APW IC GATE AND 3CH 3-INP 14TSSOP Texas Instruments	6,840	0.12	RFQ		Bulk	74HC	Active	AND Gate	3	3	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	17ns @ 6V, 50pF	-40°C ~ 85°C	Surface Mount
74LS260PC IC GATE NOR 2CH 5-INP 14DIP National Semiconductor	6,773	0.12	RFQ	Datasheet	Bulk	74LS	Active	NOR Gate	2	5	-	4.75V ~ 5.25V	5.5 mA	400µA, 8mA	0.8V	2V	12ns @ 5V, 15pF	0°C ~ 70°C	Through Hole
