Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	LogicType	NumberofCircuits	NumberofInputs	Features	Voltage-Supply	Current-Quiescent(Max)	Current-OutputHighLow	LogicLevel-Low	LogicLevel-High	MaxPropagationDelay@VMaxCL	OperatingTemperature	MountingType
TC7SHU04F,LJ(CT IC INVERTER 1CH 1-INP SMV Toshiba Semiconductor and Storage	2,940	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	TC7SHU	Active	Inverter	1	1	-	2V ~ 5.5V	2 µA	8mA, 8mA	0.3V	1.7V	7ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
TC7WH02FU,LJ(CT IC GATE NOR 2CH 2-INP SM8 Toshiba Semiconductor and Storage	2,831	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	TC7WH	Active	NOR Gate	2	2	-	2V ~ 5.5V	2 µA	8mA, 8mA	-	-	7.5ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
TC7WZ04FU,LJ(CT IC INVERTER 3CH 3-INP US8 Toshiba Semiconductor and Storage	2,528	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	TC7WZ	Active	Inverter	3	3	-	1.65V ~ 5.5V	10 µA	32mA, 32mA	-	-	3.6ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
74LVC1G86FZ4-7 IC GATE XOR 1CH 2-INP DFN1410-6 Diodes Incorporated	1,905	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	XOR (Exclusive OR)	1	2	-	1.65V ~ 5.5V	200 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	5.5ns @ 5V, 50pF	-40°C ~ 125°C (TA)	Surface Mount
SN74AHC02DR IC GATE NOR 4CH 2-INP 14SOIC Texas Instruments	1,238	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74AHC	Active	NOR Gate	4	2	-	2V ~ 5.5V	2 µA	8mA, 8mA	0.5V ~ 1.65V	1.5V ~ 3.85V	8.5ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
NL17SH14P5T5G IC INVERT SCHMITT 1CH 1IN SOT953 onsemi	1,697	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	17SH	Obsolete	Inverter	1	1	Schmitt Trigger	1.65V ~ 5.5V	1 µA	8mA, 8mA	0.9V ~ 1.65V	2.2V ~ 3.85V	10.6ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
M74HC00TTR IC GATE NAND 4CH 2-INP 14TSSOP STMicroelectronics	1,607	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74HC	Obsolete	NAND Gate	4	2	-	2V ~ 6V	1 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	13ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
SN74AHC08PWR IC GATE AND 4CH 2-INP 14TSSOP Texas Instruments	430	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74AHC	Active	AND Gate	4	2	-	2V ~ 5.5V	2 µA	8mA, 8mA	0.5V ~ 1.65V	1.5V ~ 3.85V	7.9ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
74LVC1G04FZ4-7 IC INVERTER 1CH 1-INP DFN1410-6 Diodes Incorporated	1,334	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	Inverter	1	1	-	1.65V ~ 5.5V	200 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	5ns @ 5V, 50pF	-40°C ~ 125°C (TA)	Surface Mount
SN74LVC2G02YEAR IC GATE NOR 2CH 2-INP 8DSBGA Texas Instruments	1,227	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Obsolete	NOR Gate	2	2	-	1.65V ~ 5.5V	10 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	4.4ns @ 5V, 50pF	-40°C ~ 125°C (TA)	Surface Mount
74LVC1G04FW4-7 IC INVERTER 1CH 1-INP DFN1010-6 Diodes Incorporated	1,097	0.40	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	Inverter	1	1	-	1.65V ~ 5.5V	200 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	3.7ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
NL17SGU04P5T5G IC INVERTER 1CH 1-INP SOT953 onsemi	2,633	0.41	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	MiniGate™	Obsolete	Inverter	1	1	-	0.9V ~ 3.6V	500 nA	8mA, 8mA	0.7V ~ 0.8V	1.7V ~ 2V	4.4ns @ 3.3V, 30pF	-55°C ~ 125°C	Surface Mount
SN74LVC1G14DPWR IC INVERT SCHMITT 1CH 1IN 5X2SON Texas Instruments	2,552	0.41	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	Inverter	1	1	Schmitt Trigger	1.65V ~ 5.5V	10 µA	32mA, 32mA	0.39V ~ 1.87V	1.16V ~ 3.33V	5ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
74LVC08AS14-13 IC GATE AND 4CH 2-INP 14SO Diodes Incorporated	2,119	0.41	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	AND Gate	4	2	-	1.65V ~ 5.5V	10 µA	24mA, 24mA	0.7V ~ 0.8V	1.7V ~ 2V	3.9ns @ 3.3V, 50pF	-40°C ~ 125°C	Surface Mount
74LV04AS14-13 IC INVERTER 6CH 1-INP 14SO Diodes Incorporated	4,497	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LV	Active	Inverter	6	1	-	2V ~ 5.5V	20 µA	12mA, 12mA	0.5V	1.5V	7.5ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
74LVC1G86FW5-7 IC GATE XOR 1CH 2-INP DFN1010-6 Diodes Incorporated	3,780	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	XOR (Exclusive OR)	1	2	-	1.65V ~ 5.5V	200 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	5.5ns @ 5V, 50pF	-40°C ~ 125°C (TA)	Surface Mount
74AUP1G04FW5-7 IC INVERTER 1CH 1-INP DFN1010-6 Diodes Incorporated	3,695	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74AUP	Active	Inverter	1	1	-	0.8V ~ 3.6V	500 nA	4mA, 4mA	0.7V ~ 0.9V	1.6V ~ 2V	5.4ns @ 3.3V, 30pF	-40°C ~ 125°C (TA)	Surface Mount
74AUP1G32FW5-7 IC GATE OR 1CH 2-INP DFN1010-6 Diodes Incorporated	3,342	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74AUP	Active	OR Gate	1	2	-	0.8V ~ 3.6V	500 nA	4mA, 4mA	0.7V ~ 0.9V	1.6V ~ 2V	6.4ns @ 3.3V, 30pF	-40°C ~ 125°C (TA)	Surface Mount
74LVC1G02FW5-7 IC GATE NOR 1CH 2-INP DFN1010-6 Diodes Incorporated	3,195	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	NOR Gate	1	2	-	1.65V ~ 5.5V	200 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	5.5ns @ 5V, 50pF	-40°C ~ 125°C (TA)	Surface Mount
74VHC27FT IC GATE NOR 3CH 3-INP 14TSSOPB Toshiba Semiconductor and Storage	3,195	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74VHC	Active	NOR Gate	3	3	-	2V ~ 5.5V	2 µA	8mA, 8mA	0.1V ~ 36V	2V ~ 4.5V	7.9ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
